Post Cosmos II
The Cosmos II is now in my hands, before it's even available for retail sale! :D

However as I feared, the HWLabs SR-1 needs an extra 5mm to fit properly without hanging over the motherboard. I have come to a possible solution, but I want your advice!

My solution to the problem, since it's basically just the EPS12V connector that is being problematic, if I remove it from the plastic connector and plug the "molex" pins directly into the motherboard, I can fit the board in fine as it tucks up in behind the radiator. Granted I haven't tried with my P6TD (which has heatsinks along the top edge) but I think it will fit. Can always chop the heatsink if needed.

But my question is, is this "safe"? I was thinking maybe using some hot-glue or something to ensure they stay in and give it some insulation in case anything leaks onto it or it touches the radiator. Pictures show how it looks.

Motherboard Connector Issue:
Image Image Image Image

And here's some pictures to show just how huge this case really is, compared to the Antec 900:
Image Image Image Image
Honestly I was a bit shocked after unboxing it although I should of known when it barely fit into the trunk of an Accord.

Extremely well built and I can see why it's receiving such rave reviews. The more I look at it, the more I want to keep it and either buy a new radiator, or proceed with my modified EPS12V connection. But that's where I need your feedback! What should I do?! :doh:
